Product Summary
Parametrics
Time (Note 1) 6.0 trr Note 1: Reverse Recovery Test Conditions: IF=IR=10mA, Irr=0.1 x IR, RL=100?. Units V mA mA mW o C/W o C o C Units V V uA pF nS Version: A07 RATINGS AND CHARACTERISTIC CURVES (BAW66/BAV70/BAV99) FIG.1- TYPICAL FORWARD VOLTAGE FIG.2- TYPICAL LEAKAGE CURRENT TA = 150 OC 100 10 TA = 65 C 1.0 O TA = 125 OC IR, REVERSE CURRENT. ( A) IF, FORWARD CURRENT (mA) 10 TA = 65 OC 0.1 TA = 25 C O TA = -40 C O 1.0 TA = 55 OC 0.01 TA = 25 OC 0.1 0.2 0.001 0.4 0.6 0.8 1.0 1.2 VF, FORWARD VOLTAGE (V) 0 10 20 30 40 50 VR, REVERSE VOLTAGE (V) FIG.3- TYPICAL CAPACITANCE 1.0 CJ , DIODE CAPACITANCE (pF) 0.9 0.8 0.7 0.6 0 2 4 6 8 VR, REVERSE VOLTAGE (V) Version: A07
Features
SOT-23, Molded plastic Terminals: Solderable per MIIL-STD-202, Method 208 Polarity: See diagram Marking: BAW56: A1, BAV70: A4, BAV99: A7 Weight: 0.008 gram (approx.) Dimensions in inches and (millimeters) Maximum Ratings Type Number TA=25℃ unless otherwise specified Symbol BAW56/BAV70/BAV99 Reverse Voltage 70 VR Forward Current 200 IF Peak Forward Surge Current 500 IFM(surge) Power Dissipation 225 PD Thermal Resistance Junction to Ambient Air 556 RθJA Junction Temperature 150 TJ Storage Temperature Range -55 to 150 TSTG Electrical Characteristics Type Number Symbol Min Max Reverse Breakdown Voltage IR=100uA 70 VR Forward Voltage IF=1.0mA 0.715 IF= 10mA 0.855 VF IF = 50mA 1.0 IF=150mA 1.25 Reverse Current VR=70V 2.5 IR Capacitance between terminals VR=0, f=1.0MHz 1.5 Cj Reverse Recovery
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BAV70,215 |
NXP Semiconductors |
Diodes (General Purpose, Power, Switching) SW DBL 75V 215MA HS |
Data Sheet |
|
|
||||||||||||
 |
BAV70_Q |
Fairchild Semiconductor |
Rectifiers 70V 200mA |
Data Sheet |
Negotiable |
|
||||||||||||
 |
BAV70DV-7 |
Diodes Inc. |
Diodes (General Purpose, Power, Switching) SURFACE MOUNT SWITCHING DIODE ARRAY |
Data Sheet |
Negotiable |
|
||||||||||||
|
BAV70DW |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BAV70M,315 |
NXP Semiconductors |
Diodes (General Purpose, Power, Switching) SWITCHING DIODE |
Data Sheet |
|
|
||||||||||||
 |
BAV70S,115 |
NXP Semiconductors |
Diodes (General Purpose, Power, Switching) DIODE SW TAPE-7 |
Data Sheet |
|
|
||||||||||||
|
BAV70T,115 |
NXP Semiconductors |
Diodes (General Purpose, Power, Switching) DIODE SW TAPE-7 |
Data Sheet |
|
|
||||||||||||
 |
BAV70T116 |
ROHM Semiconductor |
Diodes (General Purpose, Power, Switching) SWITCH HI SPEED |
Data Sheet |
|
|
||||||||||||
