Product Summary

The ESDA6V1L is a 5-bit wide monolithic suppressor which is designed to protect against ESD components connected to data and transmission lines. The ESDA6V1L is suitable for where transient overvoltage protection in ESD sensitive equipment is required, such as: (1)Computers; (2)Printers; (3)Communication systems; (4)Cellular phone handsets and accessories; (5)Other telephone sets; (6)Set top boxes.

Parametrics

ESDA6V1L absolute maximum ratings: (1)PPP Peak pulse power: 100 W; (2)Tj Junction temperature: 150℃; (3)Tstg Storage temperature range: -55 to +150℃; (4)TL Lead solder temperature (10 seconds duration): 260℃; (5)Top Operating temperature range: -40 to +125℃.

Features

ESDA6V1L features: (1)5 unidirectional transil functions; (2)breakdown voltage: VBR = 6.1V min; (3)low leakage current: IR max<1 μA.

Diagrams

ESDA6V1L block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ESDA6V1L
ESDA6V1L

STMicroelectronics

TVS Diode Arrays 6.1V 300W Unidirect

Data Sheet

0-1: $0.22
1-10: $0.19
10-100: $0.14
100-250: $0.13
ESDA6V1L-TP
ESDA6V1L-TP

Micro Commercial Components (MCC)

TVS Diodes - Transient Voltage Suppressors 6.1V 300W

Data Sheet

0-1: $0.19
1-100: $0.14
100-500: $0.10
500-1000: $0.08
