Product Summary

NOTES: A. All linear dimensions are in millimeters.
B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion not to exceed 0,15.
D. Falls within JEDEC MO-153

Parametrics

 Wide Supply Range:
? Single Supply ...3 V to 32 V
(26 V for LM2904)
? or Dual Supplies . . .  1.5 V to  16 V
(  13 V for LM2904)
 Low Supply-Current Drain, Independen
Supply Voltage. . . 0.7 mA Typ
 Common-Mode Input Voltage Range
Includes Ground, Allowing Direct Sensi
Near Ground
 Low Input Bias and Offset Parameters:
? Input Offset Voltage ...3 mV Typ
A Versions...2 mV Typ
? Input Offset Current ...2 nA Typ
? Input Bias Current . . . 20 nA Typ
A Versions. . . 15 nA Typ
 Differential Input Voltage Range Equal t
Maximum-Rated Supply Voltage...32 V
(26 V for LM2904)
 Open-Loop Differential Voltage
Amplification. . . 100 V/mV Typ
 Internal Frequency Compensation

Features

These devices consist of two independent,
high-gain, frequency-compensated operational
amplifiers designed to operate from a single
supply over a wide range of voltages. Operation from split supplies also is possible if the difference between
the two supplies is 3 V to 32 V (3 V to 26 V for the LM2904), and V
CC
is at least 1.5 V more positive than the
input common-mode voltage. The low supply-current drain is independent of the magnitude of the supply
voltage.
Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational
amplifier circuits that now can be implemented more easily in single-supply-voltage systems. For example,
these devices can be operated directly from the standard 5-V supply used in digital systems and easily can
provide the required interface electronics without additional ± 5-V supplies.
